Planetary gear reducer for vibrating screen

The reducer plays the role of matching the speed and transmitting torque between the prime mover and the working machine or the actuator. It is a relatively precise machine. The purpose of using it is to reduce the speed and increase the torque. It has a wide variety of different models, and different types have different uses. There are many types of reducers, which can be divided into gear reducers, worm reducers and planetary gear reducers according to the transmission type.

The planetary gear reducer has the characteristics of light weight, small size, large transmission ratio range, high efficiency, stable operation, low noise and strong adaptability. Reducers are widely used in metallurgy, mining, lifting and transportation, electric power, energy, building materials, light industry, transportation and other industrial fields.

Features

1. The planetary gear reducer adopts modular design, which can be changed and combined according to customer requirements.
2. The reducer adopts involute planetary gear transmission, which makes reasonable use of internal and external meshing and power splitting.
3. The box body is made of nodular cast iron, which greatly improves the rigidity and shock resistance of the box body.
4. The gears are all carburized and quenched to obtain a high-hard wear-resistant surface. All gears are ground after heat treatment, which reduces noise and improves the efficiency and service life of the whole machine.
5. There are 2 and 3 planetary transmission stages.

Reduction ratio: 25～4000r/min
Output torque: up to 2600000Nm
Motor power: 0.4-12934kW

Installation form

1. Foot installation
2. Flange installation
3. Installation of torque arm.
